Android技巧一之启动屏+新功能左右导航逻辑

package com.devilwwj.featureguide;
import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.os.Handler;
import com.devilwwj.featureguide.global.AppConstants;
import com.devilwwj.featureguide.utils.SpUtils;
/**
* @desc 启动屏
* Created by devilwwj on 16/1/23.
*/
public class SplashActivity extends Activity {
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
// 判断是否是第一次开启应用
boolean isFirstOpen = SpUtils.getBoolean(this, AppConstants.FIRST_OPEN);
// 如果是第一次启动，则先进入功能引导页
if (!isFirstOpen) {
Intent intent = new Intent(this, WelcomeGuideActivity.class);
startActivity(intent);
finish();
return;
}
// 如果不是第一次启动app，则正常显示启动屏
setContentView(R.layout.activity_splash);
new Handler().postDelayed(new Runnable() {
@Override
public void run() {
enterHomeActivity();
}
}, 2000);
}
private void enterHomeActivity() {
Intent intent = new Intent(this, MainActivity.class);
startActivity(intent);
finish();
}
}

代码解析：使用SharedPreference来保存app启动状态，如果为true，则进入功能导航，否则延迟2秒之后进入主页面。

WelcomeGuideActivity.java
package com.devilwwj.featureguide;
import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.support.v4.view.ViewPager;
import android.support.v4.view.ViewPager.OnPageChangeListener;
import android.view.LayoutInflater;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.Button;
import android.widget.ImageView;
import android.widget.LinearLayout;
import com.devilwwj.featureguide.global.AppConstants;
import com.devilwwj.featureguide.utils.SpUtils;
import java.util.ArrayList;
import java.util.List;
/**
* 欢迎页
*
* @author wwj_748
*
*/
public class WelcomeGuideActivity extends Activity implements OnClickListener {
private ViewPager vp;
private GuideViewPagerAdapter adapter;
private List<View> views;
private Button startBtn;
// 引导页图片资源
private static final int[] pics = { R.layout.guid_view1,
R.layout.guid_view2, R.layout.guid_view3, R.layout.guid_view4 };
// 底部小点图片
private ImageView[] dots;
// 记录当前选中位置
private int currentIndex;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_guide);
views = new ArrayList<View>();
// 初始化引导页视图列表
for (int i = 0; i < pics.length; i++) {
View view = LayoutInflater.from(this).inflate(pics[i], null);
if (i == pics.length - 1) {
startBtn = (Button) view.findViewById(R.id.btn_login);
startBtn.setTag("enter");
startBtn.setOnClickListener(this);
}
views.add(view);
}
vp = (ViewPager) findViewById(R.id.vp_guide);
// 初始化adapter
adapter = new GuideViewPagerAdapter(views);
vp.setAdapter(adapter);
vp.setOnPageChangeListener(new PageChangeListener());
initDots();
}
@Override
protected void onResume() {
super.onResume();
}
@Override
protected void onPause() {
super.onPause();
// 如果切换到后台，就设置下次不进入功能引导页
SpUtils.putBoolean(WelcomeGuideActivity.this, AppConstants.FIRST_OPEN, true);
finish();
}
@Override
protected void onStop() {
super.onStop();
}
@Override
protected void onDestroy() {
super.onDestroy();
}
private void initDots() {
LinearLayout ll = (LinearLayout) findViewById(R.id.ll);
dots = new ImageView[pics.length];
// 循环取得小点图片
for (int i = 0; i < pics.length; i++) {
// 得到一个LinearLayout下面的每一个子元素
dots[i] = (ImageView) ll.getChildAt(i);
dots[i].setEnabled(false);// 都设为灰色
dots[i].setOnClickListener(this);
dots[i].setTag(i);// 设置位置tag，方便取出与当前位置对应
}
currentIndex = 0;
dots[currentIndex].setEnabled(true); // 设置为白色，即选中状态
}
/**
* 设置当前view
*
* @param position
*/
private void setCurView(int position) {
if (position < 0 || position >= pics.length) {
return;
}
vp.setCurrentItem(position);
}
/**
* 设置当前指示点
*
* @param position
*/
private void setCurDot(int position) {
if (position < 0 || position > pics.length || currentIndex == position) {
return;
}
dots[position].setEnabled(true);
dots[currentIndex].setEnabled(false);
currentIndex = position;
}
@Override
public void onClick(View v) {
if (v.getTag().equals("enter")) {
enterMainActivity();
return;
}
int position = (Integer) v.getTag();
setCurView(position);
setCurDot(position);
}
private void enterMainActivity() {
Intent intent = new Intent(WelcomeGuideActivity.this,
SplashActivity.class);
startActivity(intent);
SpUtils.putBoolean(WelcomeGuideActivity.this, AppConstants.FIRST_OPEN, true);
finish();
}
private class PageChangeListener implements OnPageChangeListener {
// 当滑动状态改变时调用
@Override
public void onPageScrollStateChanged(int position) {
// arg0 ==1的时辰默示正在滑动，arg0==2的时辰默示滑动完毕了，arg0==0的时辰默示什么都没做。
}
// 当前页面被滑动时调用
@Override
public void onPageScrolled(int position, float arg1, int arg2) {
// arg0 :当前页面，及你点击滑动的页面
// arg1:当前页面偏移的百分比
// arg2:当前页面偏移的像素位置
}
// 当新的页面被选中时调用
@Override
public void onPageSelected(int position) {
// 设置底部小点选中状态
setCurDot(position);
}
}
}
