Android自定义滑动解锁控件使用详解

<!-- 滑动解锁控件 xml配置属性 -->
<declare-styleable name="SlideToUnlockView">
 <attr name="slideImageViewWidth" format="dimension"/><!-- 滑块宽度 -->
 <attr name="slideImageViewResId" format="reference"/><!-- 滑块资源id -->
 <attr name="slideImageViewResIdAfter" format="reference"/><!-- 滑动到右边时,滑块资源id -->
 <attr name="viewBackgroundResId" format="reference"/><!-- 背景资源id -->
 <attr name="textHint" format="string"/><!-- 文本内容 -->
 <attr name="textSize" format="integer"/><!-- 文本字号 -->
 <attr name="textColorResId" format="color"/><!-- 文本字色 -->
 <attr name="slideThreshold" format="float"/><!-- 滑动阈值,默认是0.5,当右滑距离不满整个控件宽度的0.5,就会回弹至左边 -->
</declare-styleable>

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
 xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:tools="http://schemas.android.com/tools"
 android:layout_width="match_parent"
 android:layout_height="match_parent"
 xmlns:chuck="http://schemas.android.com/apk/res-auto"
 android:paddingBottom="@dimen/activity_vertical_margin"
 android:paddingLeft="@dimen/activity_horizontal_margin"
 android:paddingRight="@dimen/activity_horizontal_margin"
 android:paddingTop="@dimen/activity_vertical_margin"
 tools:context="com.qdong.slidetounlockdemo.MainActivity">


 <RelativeLayout
 android:layout_width="match_parent"
 android:layout_height="wrap_content"
 android:id="@+id/relativeLayout">

 <!-- chuck:textSize="14sp"
   chuck:textColorResId="@color/colorWhite"-->
 <com.qdong.slide_to_unlock_view.CustomSlideToUnlockView
  android:id="@+id/slide_to_unlock"
  android:layout_width="match_parent"
  android:layout_height="50dp"


  chuck:viewBackgroundResId="@drawable/shape_round_normal_green"
  chuck:slideImageViewWidth="@dimen/slide_width"
  chuck:slideImageViewResId="@mipmap/icon_slide"
  chuck:slideImageViewResIdAfter="@mipmap/ic_launcher"
  chuck:slideThreshold="0.5"
  chuck:textSize="6"
  chuck:textHint="@string/hint"
  chuck:textColorResId="@color/colorWhite"

  >

 </com.qdong.slide_to_unlock_view.CustomSlideToUnlockView>

 </RelativeLayout>

 <Button
 android:layout_width="wrap_content"
 android:layout_height="wrap_content"
 android:text="reset"
 android:id="@+id/button"
 android:layout_below="@+id/relativeLayout"
 android:layout_centerHorizontal="true"
 android:layout_marginTop="150dp"/>

 <TextView
 android:layout_width="wrap_content"
 android:layout_height="wrap_content"
 android:id="@+id/tv_text"
 android:text="slide distance:"
 android:layout_alignBottom="@+id/button"
 android:layout_centerHorizontal="true"
 android:layout_marginBottom="60dp"/>

</RelativeLayout>

public class MainActivity extends AppCompatActivity {

 private com.qdong.slide_to_unlock_view.CustomSlideToUnlockView mCustomSlideToUnlockView;
 private TextView tv_text;

 @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_main);
 mCustomSlideToUnlockView= (com.qdong.slide_to_unlock_view.CustomSlideToUnlockView) findViewById(R.id.slide_to_unlock);
 tv_text= (TextView) findViewById(R.id.tv_text);

 CustomSlideToUnlockView.CallBack callBack=new CustomSlideToUnlockView.CallBack() {
  @Override
  public void onSlide(int distance) {
  tv_text.setText("slide distance:"+distance);
  }

  @Override
  public void onUnlocked() {
  tv_text.setText("onUnlocked");
  }
 };
 mCustomSlideToUnlockView.setmCallBack(callBack);
 findViewById(R.id.button).setOnClickListener(new View.OnClickListener() {
  @Override
  public void onClick(View view) {
  mCustomSlideToUnlockView.resetView();
  }
 });
 }
}
